Product Introduction:

Glass name: 15mm ultra clear tempered glass,15mm super clear tempered glass

Other name: low iron tempered glass,ultra clear tempered glass

Thickness: 15mm

Other thk: 3mm 4mm 5mm 6mm 8mm 10mm 12mm 15mm 19mm 25mm

Size: Customized size (Max : 3300 x 13000mm, Min: 300 x 300mm)

Package: Exportation wooden crates

Share

Product details

BTG-15mm ultra clear tempered glass,15mm super clear tempered glass-Perfect building glass for glass handrail, glass balustrade, glass swimming pool fence


15mm ultra-clear tempered glass,15mm super clear tempered glass (also called toughened glass, full tempered glass, short for FT)is a type of glass with even compressive stress on the surface which is made by heating float glass to nearly softening point and then cooling it down rapidly by air. During the instant cooling process, the exterior of the glass is solidified due to rapid cooling while the interior of the glass is cooled down relatively slowly. This process will bring the glass surface compressive stress and the interior tensile stress which can improve the mechanical strength of glass by germination and result in good thermal stability.


Characteristic

Safety

When the glass is impacted, it is not easy to break. When the glass is broken, it is similar to honeycomb-shaped small obtuse-angle particle fragments, and will not cause serious harm to human body.


High Intensity

Toughened glass has 3-5 times higher impact strength than float glass of the same thickness.


Large Deflection

Compared with ordinary glass of the same thickness, the deflection of tempered glass is 3-4 times larger than that of ordinary glass. When the tempered glass is subjected to load, its maximum tensile stress is not located on the surface of the glass as ordinary glass, but in the center of the tempered glass plate.


Thermal Stability

Tempered glass has good thermal stability. Compared with ordinary glass of the same thickness, the thermal impact strength of tempered glass is three times higher, and the temperature range of abrupt change is 220 - 250℃ . Compared with ordinary glass, the temperature range of tempered glass is only 70 - 100℃ . When tempered glass is subjected to a certain quench temperature, the compressive stress on the surface of the tempered glass is opposite to the tensile stress direction and cancels each other. Tempered glass is subjected to extreme heat, the surface produces compressive stress, beca use the glass compressive stress is several times the tensile stress, so tempered glass can also withstand a certain degree of hot temperature.


Specification

Thickness: 15mm

Available Size: Min size: 300×300mm,max size: 3300×13000mm

Color: Clear,ultra clear,euro gray,dark grey,F green,dark green,Ford blue,dark blue,etc

Edge: Polished edge(c edge,pencil edge),flat edge,drill hole,etc


Application

Building Curtain wall, Windows, Doors, Exhibition Hall, Shower Room, Furniture Glass.


Product details:

Sr.ItemGlass TypeMaterial optionThickness(mm)

PVB/EVA/SGP/Alu.

 thickness(mm)

SizeRemark
Min.(mm)Max(mm)
1Building GlassTempered   Glass(Monolithic)Clear glass3-25/200*3003300*13000Contact us for more   information
2Low iron /Ultra clear glass3-25/200*3003300*13000
3Tinted glass3-19/200*3003300*13000
4Coated/Reflective glass5,6,8,10/200*3003300*13000
5Low E glass5,6,8,10/200*3003300*13000
6Curved Tempered   Glass(Monolithic)Clear glass3-25/

Radius>1000mm

,Radius<1000mm

7Low iron /Ultra clear glass3-25/
8Tinted glass3-25/
9Coated/Reflective glass5,6,8,10/
10Low E glass5,6,8,10/
11Laminated GlassClear glass3-25 up0.38,0.76,1.14 up200*3003300*6500
12Low iron /Ultra clear glass3-25 up0.38,0.76,1.14 up200*3003300*6500
13Tinted glass5,6,8,10,12 up0.38,0.76,1.14 up200*3003300*6500
14Coated/Reflective glass5,6,8,10,12 up0.38,0.76,1.14 up200*3003300*6500
15Insulated GlassClear glass3-256,9,12,16,,18,20 up200*3003300*6500
16Low iron /Ultra clear glass3-256,9,12,16,,18,20 up200*3003300*6500
17Tinted glass3-256,9,12,16,,18,20 up200*3003300*6500
18Coated/Reflective glass5,6,8,106,9,12,16,,18,20 up200*3003300*6500
19Low E glass5,6,8,106,9,12,16,,18,20 up200*3003300*6500
20Bullet Proof GlassBullet Proof Glass
0.76 up200*3002450*4500
21Fire Proof GlassSingle piece5-15/200*3003000*40000.5h,1h,1.5h,2h,3h
22Compound glass5-45Customized200*3003300*6500
23Switchable GlassSwitchable glass6-240.38,0.76,1.14 up200*3001800*6000Contact us for more   information
24Louver Product
5-199,12,16,,18,20 up200*3003300*6500
25Sound Proof GlassSound proof glass5-19Customized200*3003300*6500
