Low Iron Glass
Product Introduction:
Ultra-clear glass is an ultra-low-transparent glass, also known as low-iron glass, high-transparent glass. It is a high-quality, multi-functional new high-grade glass variety, with a light transmittance of 91.5% or more. It is characterized by its crystal clearness and high-grade elegance. It is known as the "crystal prince" in the glass family. Ultra-white glass also possesses all the machinable properties of high-quality float glass, with excellent physical, mechanical and optical properties. It can perform various deep processing like other high-quality float glass. Incomparable superior quality and product performance make ultra-white glass has a vast application space and bright market prospects.
Product details
Characteristic
1. Smooth surface,good perspective.
2. Specification can be customized to increase using rate.
3. Provides material for making various levels of proessing.
Applications
Car windows and the interior of the hose,mirror,display,cabinet,
ceramic silkscreen glass,picture frame,glass furniture and table tops.
Thickness Range
2mm 3mm 4mm 5mm 6mm 8mm 10mm 12mm 15mm 19mm 22mm 25mm
Size Range
1650mm*2140mm 2140mm*3300mm 2140mm*3660mm 2250mm*3300mm
2250mm*3660mm 2440mm*3300mm 2440mm*3660mm 1220mm*1830mm
1830mm*2440mm 1830mm*2600mm 2600mm*3660mm
Max Size:3300mm*18000mm
Any other size can be produced as customer's requirements
| No. | Extra Clear Glass | Visible Light Transmittance | Visble Reflectivity | Solar Energy Transmittance | Solar Energy Reflectivity | Total Solar Energy Transmittance |
| 1 | 3mm | 91.50 | 8.48 | 91.20 | 8.32 | 91.50 |
| 2 | 3.2mm | 91.45 | 8.48 | 91.13 | 8.33 | 91.30 |
| 3 | 4mm | 91.32 | 8.50 | 90.86 | 8.35 | 91.00 |
| 4 | 5mm | 91.21 | 9.51 | 90.60 | 8.34 | 90.30 |
| 5 | 6mm | 91.16 | 8.54 | 90.31 | 8.36 | 90.10 |
| 6 | 8mm | 91.02 | 7.11 | 90.10 | 8.34 | 89.60 |
| 7 | 10mm | 90.85 | 7.09 | 88.50 | 8.24 | 88.60 |
| 8 | 12mm | 90.62 | 6.73 | 87.80 | 8.18 | 88.00 |
| 9 | 15mm | 90.43 | 7.58 | 85.60 | 8.05 | 88.00 |
| 10 | 19mm | 90.01 | 7.12 | 83.90 | 7.92 | 86.20 |
